THE MARINE COUNTERPART

The Marine White Boat Curved 31 inch ST2K 12 LED Light Bar is the exemplar of marine lighting performance. Armed with Super- Drive LEDs, the ST2K 31 Inch 12 LED Light Bar delivers an uncompromised 12000 Lumens, perfectly suited for any water-based activities. Just hit the ‘on’ button to witness the innovative Super-Drive reflector systems delivering an unmatched light intensity.

STEDI ST2K Marine White 31 Inch 12 LED Curved Light Bar

PROTECTION GUARANTEED

With an IP68 rating and Marine Grade Powder Coat, not to mention E-Mark R10 & CE certifications, the ST2K Marine 31 Inch Curved LED Light Bar is designed to brave the harshest conditions.

STEDI ST2K Marine White 31 Inch 12 LED Curved Light Bar

CUTTING-EDGE TECHNOLOGY

The ST2K Marine 31 Inch Curved LED Light Bar is integrated with 20 x 15W rearward-facing high-powered LEDs, allowing for a whole new level of beam intensity & control that is unfound in traditional reflector designs.

STEDI ST2K Marine White 31 Inch 12 LED Curved Light Bar

LUX CHART

STEDI ST2K Marine White 31 Inch 12 LED Curved Light Bar

DIMENSIONS

STEDI ST2K Marine White 31 Inch 12 LED Curved Light Bar dimensions

NIGHT SHOT

STEDI ST2K Marine White 31 Inch 12 LED Curved Light Bar night shot

THE NERDY TECH STUFF

THE NITTY-GRITTY

ADVANTAGES OF A LATERAL SPOT BEAM

Excellent well rounded mid to long-range illumination
Significantly minimizes adverse reflection from road signs
Eliminates light wasted on illuminating tree tops (won’t disturb sleeping koalas)
An excellent alternative to HID, without the associated downsides
The beam is 139m wide at approx 575m

KEY FEATURES

LED Parking / Position Light Function
Breather allows pressure equalization when rapid heat up and cool down cycles occur.
Lumes: 12000
Anodized Polyester Powder Coat
Weatherproof Deutsch® DT2 Connector.
Includes adjustable side brackets
Protected against reverse polarity
Shockproof, IP68 waterproof, UV Shielded
Protected against RFI / EMC Interference
Voltage & current surge protection
Pulse Width Modulation Thermal Management

NOTE: NO HARNESS INCLUDED.

TECH SPECS

MAIN BEAM LED COUNT	12 x 15W
VOLTAGE	12V & 24V
LENS MATERIAL	Optical Grade, Hard Coated Lexan
LUMENS	12,000
HOUSING MATERIAL	6063 Extrusion
AMPERES	12.4A @ 13.2v
LIFESPAN	50,000
SPOT BEAM	Driving Beam
INGRESS PROTECTION	IP68
OPERATING TEMP	-40°C ~ +150°C
WEIGHT	3.645kg
CERTIFICATES	E-Mark R10 \| CE ✓

WHAT'S IN THE BOX

1 x 31" ST2K-12L LED Light Bar
2 x Steel Side Brackets
Comprehensive 316 Stainless Steel fasteners
